Aperture: TC12 mm

Nonlinearity: <3.5 mrad over 44° (mechanical)

Step response time (1 % of full scale): <0.7 ms

Tracking error: 0.3 ms

Gain drift: <80 PPM/K

Zero offset drift: <20 µrad/°C

Repeatability: <20 µrad

Aging drift (after 30‑min warm‑up, over 8 hrs): <0.5 mrad

Marking speed: 3000 mm/s

Positioning speed: 8 m/s

Scan angle: ±0.35 rad

Resolution: 40 µrad

Mirror coating: 10600 nm

Power supply: ±15 VDC, 2 A max per rail

Clear aperture: 7.0 mm

Operating temperature: 25 °C ± 10 °C
