Scanner Motor Specifications:

Nonlinearity: < 2 mrad / 44°

1% Full-Scale Step Response Time: ≤ 0.50 ms

Tracking Error: 0.3 ms

Gain Drift: < 40 ppm / K

Zero Offset Drift: < 20 µrad / °C

Long-Term Drift (8 h, after 30 min warm-up): < 0.5 mrad

Repeatability: < 40 µrad

Typical Scan Angle: ± 0.35 rad

Positioning Resolution: 20 µrad

Mirror Coating / Reflection Wavelength: 10,600 nm

Power Requirements: ±15 VDC, max. 3 A each

Clear Aperture: 7 mm

Operating Temperature: 25 °C ± 10 °C
