Front connector: Internal thread M17x0.75, Depth: 6 mm

Extended length: 1188 mm (Short) / 1303 mm (Long) (Excluding handpiece)

Wavelength: 10.6 μm, 650 nm

Beam deviation: ±0.7

Number of joints: 7

Mirror size:Φ25*3, Φ20*3

Aperture diameter: Φ12 mm

Single mirror reflectivity: >99.5% @ 10.6 μm

Cutting head focal length: F=100 mm

Transmission efficiency: >85% @ 10.6 μm

Housing material: AL6063

Surface finish: Sandblasted & Anodized

Gross weight: 5.3 kg (Short) / 5.5 kg (Long) (Including package)

Package dimension: 67*24*15 cm (Short) / 75*24*15 cm (Long)
