Front connector: Internal thread M17x0.75, Depth: 6 mm

Extended length: 1300 mm (Excluding handpiece)

Wavelength: 10.6 μm,650 nm

Beam deviation:±0.7

Number of joints: 7

Mirror size:Φ25*3, Φ20*3

Aperture diameter: Φ12 mm

Single mirror reflectivity: >99.5% @ 10.6 μm

Cutting head focal length: F=100 mm

Transmission efficiency: >85% @ 10.6 μm

Housing material: AL6063

Surface finish: Sandblasted & Anodized

Gross weight: 5.02 kg (Including package)

Package dimension:72*24*12 cm
