Front connector: Internal thread M17x0.75, Depth:6 mm

Extended length: 1268 mm (Short) / 1303 mm (Long) (Excluding handpiece)

Wavelength: 10.6 μm, 650 nm

Beam deviation: ±0.7

Number of joints:7

Mirror size: Φ25*3, Φ20*3

Aperture diameter: @12 mm

Single mirror reflectivity:>99.5%@10.6 μm

Cutting head focal length: F=100 mm

Transmission efficiency: >85% @ 10.6 μm

Housing material: AL6063

Surface finish: Sandblasted & Anodized

Gross weight: 5.65 kg (Short) / 5.69 kg (Long) (Including package)

Package dimension:75*24*15 cm
