Front connector: Internal thread M17x0.75, Depth: 6 mm

Extended length: 1233 mm(6 joints) / 1271 mm (7 joints)

(Excluding handpiece)

Wavelength: 10.6 μm, 650 nm

Beam deviation: ±0.7

Number of joints:6/7 joints optional

Mirror size: Φ25*3, Φ20*3

Aperture diameter: Φ10 mm

Single mirror reflectivity:>99.5%@ 10.6 μm

Cutting head focal length:F=100 mm

Transmission efficiency: >85% @10.6 μm

Housing material: AL6063

Surface finish: Sandblasted & Anodized

Gross weight: 4.52 kg (Including package)

Package dimension: 72*24*12 cm
